Ironworth Rural

Name: Ironworth Rural
SKU: ironworth-rural

6-way hydraulic grader blade with lift, angle and tilt for rural contractors and council maintenance crews.

Overview

Designed for rural contractors, councils and property maintenance operators who require greater versatility and precision while retaining the simplicity and reliability of conventional hydraulic controls.

Features

6-way blade configuration
Hydraulic lift, angle and tilt functions
Independent hydraulic valve control
Heavy-duty chassis and mouldboard
Compatible with all skid steer loaders (70hp–120hp) and compact track loaders (50hp–120hp)

Benefits

Greater versatility for a wider range of grading applications
Improved control for shaping drains, roads and batters
Simple hydraulic operation with proven reliability
No specialised electronics or automation required
Suitable for contractors servicing multiple property types
Built for regular commercial use

Starting from $32,180 + GST

Request Quote

Specifications

Ironworth Rural specifications

Attachment Length: 2.1m
Attachment Height: 1m
Blade Width: 2.2m (with bolt-on extensions: 2.5m, 2.8m)
Blade Width Angled: 1.8m
Blade Height: 500mm
Blade Orientation: Lift, angle, tilt
Blade Lift Travel: 300mm
Blade Rotation Angle: +/-35 degrees
Blade Tilt Slope: +/-17 degrees
Hitch: Universal skid-steer mount
Build: Australian designed & manufactured
Maintenance: Greasable pivot points, standard reversable cutting edges
Options: Blade extensions, side wings, rear hinged cutting-edge, customisations
Control: Standard auxiliary hydraulic manual control with electric function diverters
Automation Compatibility: Not compatible
